3 Bedroom House Plan - ID 23404

This simple three bedroom house plan is ideal for a modern family. Each room is en-suite with it's own bathroom, shower and WC. Due to its compact size, it can fit on a rather small plot measuring only 11 meters x 20 meters (36 ft x 65 ft). It has a partially covered parking under the master bedroom balcony which can be extended using a canopy. A great plan for individuals and for real-estates.

Plan Details

Features Drawings List
Stories: 2
Bedroom: 3
Self-contained rooms: 3
Toilets: 4
Kitchen: 1
Living room: 1
Balcony: 1
Verandah: 2
Laundry: 1, Store: 3

Foundation Plan
Floor Plan
Roof Plan
Sections
Elevations
Door and Window Schedule
Hot and cold water system
Waste and foul water drainage
Schematic electrical layout
Furniture layout
Structural Drawings

*Drawings delivered in PDF and DWG Format
